Our full set wall-mounted off-grid photovoltaic energy storage system provides six complete power capacity options: 5KW, 10KW, 15KW, 20KW, 30KW, 40KW single-phase 220/230V AC output, an integrated all-in-one off-grid power generation solution for remote mountain houses, rural self-built homes, farms, villas, fishing boats, construction sites and areas without grid power supply. Each complete kit adopts brand new Grade A 610W monocrystalline silicon solar panels matched with corresponding quantity, paired with IP65 waterproof combiner box, hybrid MPPT inverter all-in-one machine, wall-mounted LiFePO4 lithium iron phosphate battery pack, PV cables, MC4 connectors and aluminum alloy solar mounting brackets, realizing full independent solar power generation, energy storage and AC power output without utility grid connection.

The whole system adopts 48V low-voltage DC architecture, the integrated hybrid inverter supports MPPT maximum power tracking charging, built-in multi-level safety protection circuit; matched wall-mounted LiFePO4 battery with built-in BMS management system and LCD real-time display screen, stable cycle life and excellent low-temperature performance. The system supports simultaneous power supply of household lighting, air conditioners, refrigerators, water pumps, industrial small equipment and other AC loads, can work continuously all day relying on solar energy storage. All components pass strict industrial grade testing, IP65 outdoor dustproof and waterproof design, suitable for long-term outdoor installation in high temperature, rainy and snowy areas. Different power models correspond to different battery capacity matching schemes, from small household 5KW to large industrial 40KW full-load power supply, to meet diversified off-grid power demand of different scenarios, supporting cross-border engineering bulk export and residential distributed off-grid photovoltaic projects.

roduct Parameter Specification of Off-Grid Solar Energy Storage System

Item	5KW Off-Grid Solar System	10KW Off-Grid Solar System	15KW Off-Grid Solar System	20KW Off-Grid Solar System	30KW Off-Grid Solar System	40KW Off-Grid Solar System
Rated AC Output Power	5KW Single Phase 220/230V	10KW Single Phase 220/230V	15KW Single Phase 220/230V	20KW Single Phase 220/230V	30KW Single Phase 220/230V	40KW Single Phase 220/230V
Solar Panel Spec	610W Mono 40.8V, 2382113430mm, 33KG/PC	610W Mono 40.8V, 2382113430mm, 33KG/PC	610W Mono 40.8V, 2382113430mm, 33KG/PC	610W Mono 40.8V, 2382113430mm, 33KG/PC	610W Mono 40.8V, 2382113430mm, 33KG/PC	610W Mono 40.8V, 2382113430mm, 33KG/PC
Panel Quantity	8pcs	16pcs	24pcs	32pcs	48pcs	64pcs
Combiner Box 1pc	IP65, 2P63A DC breaker, SPD 2P20-40KA, DC500V fuse	1pc IP65, 2P63A DC breaker, SPD 2P20-40KA, DC500V fuse	1pc IP65, 2P63A DC breaker, SPD 2P20-40KA, DC500V fuse	2pcs IP65 combiner box	2pcs IP65 combiner box	4pcs IP65 combiner box
Hybrid Inverter Model	48V 5.5KW MPPT all-in-one, MPPT 100A max, PV 120-500V 2pcs	48V 5.5KW MPPT all-in-one 3pcs	48V 5.5KW MPPT all-in-one 2pcs	48V 10KW MPPT all-in-one, MPPT 160A max, PV 60-500V 3pcs	48V 10KW MPPT all-in-one 4pcs	48V 10KW MPPT all-in-one
LiFePO4 Battery Pack	51.2V 100AH, 5.12KWH wall-mounted	51.2V 200AH, 10.24KWH wall-mounted	51.2V 300AH, 15.36KWH movable 2pcs	51.2V 200AH, total 20.48KWH wall-mounted 2pcs	51.2V 300AH, total 30.72KWH movable 4pcs	51.2V 200AH, total 40.96KWH wall-mounted
PV Cable (4mm²)	50m red + 50m black	100m red + 100m black	150m red + 150m	black 200m red + 200m black	300m red + 300m black	400m red + 400m black
MC4 Connector	8pcs	16pcs	24pcs	30pcs	50pcs	60pcs
Supporting Bracket	1set Aluminum PV mounting bracket	1set Aluminum PV mounting bracket	1set Aluminum PV mounting bracket	1set Aluminum PV mounting bracket	1set Aluminum PV mounting bracket	1set Aluminum PV mounting bracket
Outer Pack Dimension(LWH cm)	51.226.567.5	523172.5	574274	523172.5	574274	523172.5
Pack Volume (cm³)	91584	116870	177156	116870	177156	116870
Total Pack Weight (g)	1999990	2999990	3999990	4999990	5999990	6999990
Installation Type	Wall-mounted whole system	Wall-mounted whole system	Wall-mounted whole system	Wall-mounted whole system	Wall-mounted whole system	Wall-mounted whole system
Output Standard	Single Phase AC 220V/230V	Single Phase AC 220V/230V	Single Phase AC 220V/230V	Single Phase AC 220V/230V	Single Phase AC 220V/230V	Single Phase AC 220V/230V

Product Feature and Application of Off-Grid Solar Energy Storage System

Core Product Competitive Advantages

Complete Full Set Integrated Matching, One-Stop Off-Grid PV Solution

Every power grade kit contains all required core components: monocrystalline solar panels, IP65 combiner box, MPPT hybrid inverter, LiFePO4 energy storage battery, PV cables, MC4 connectors and aluminum mounting brackets. Customers do not need to purchase accessories separately, complete installation matching drawings and English operation manuals are provided, greatly simplifying engineering construction and overseas after-sales maintenance.

High Efficiency 610W Monocrystalline Solar Panels with Stable Power Generation

Adopts brand new Grade A 182 monocrystalline silicon cells, excellent weak light response performance, stable power output on cloudy, dawn and dusk days. The panel surface is covered with high-transmittance tempered glass, aluminum alloy frame with anti-corrosion oxidation treatment, long outdoor service life, power tolerance controlled within 0~+5W to guarantee actual power higher than nominal value.

All-In-One MPPT Hybrid Inverter Dual Function of Charging & Inverting

Integrated MPPT solar charging controller and AC sine wave inverter in one unit, maximum MPPT tracking current up to 160A for high-power models, wide PV input voltage range 60-500V, high charging efficiency. Built-in short circuit, overvoltage, overload, reverse connection protection, pure sine wave AC output, compatible with inductive loads such as air conditioners, water pumps and refrigerators without damage.

Wall-Mounted LiFePO4 Battery with Intelligent BMS Protection

Lithium iron phosphate energy storage battery with wall-mounted design, partial high-capacity models adopt movable wheeled cabinet for convenient transfer. Built-in full BMS battery management system, real-time LCD screen displays voltage, current, remaining capacity, supporting network communication remote monitoring. Ultra-long cycle life, low self-discharge rate, excellent low-temperature resistance for mountain and cold region use.

Multi-Grade Power Selection, Adapt to All Off-Grid Scenarios

5KW/10KW: Small villa, rural family daily lighting, household small electrical equipment power supply;

15KW/20KW: Medium farm, fishing boat, construction temporary power, multi-room residential full load power supply;

30KW/40KW: Large farm irrigation, factory workshop equipment, mountain centralized off-grid power station, commercial off-grid energy storage projects.

IP65 combiner box and waterproof PV accessories fully adapt outdoor all-weather environment, aluminum alloy bracket supports roof, ground and wall installation.

Wide Applicable Scenarios

This complete off-grid solar storage system is widely used in all grid-less power supply scenarios:

Rural Residential Off-Grid: Mountain remote villages, rural self-built houses without grid access, border pastoral family independent power supply

Agricultural & Pastoral Industry: Farm irrigation water pump power, livestock breeding farm lighting, greenhouse supplementary power supply

Construction & Temporary Engineering: Highway construction site temporary power, mountain mining equipment power, field monitoring base station power supply

Special Off-Grid Scenes: Yacht & fishing boat power supply, desert signal base station, outdoor camping large energy storage, island independent power station

Commercial Villa Projects: Holiday villa off-grid energy storage, scenic spot independent power supply, remote hotel full photovoltaic power generation

Production Details of Off-Grid Solar Energy Storage System

Monocrystalline Solar Panel Lamination & Frame Craft

Each 610W monocrystalline panel undergoes EL hidden defect inspection before delivery, high-temperature lamination with double EVA film to eliminate internal bubbles. The aluminum frame adopts integrated extrusion anti-rust coating, four-corner reinforced anti-collision structure, matching MC4 waterproof connectors to avoid DC line short circuit outdoors.

MPPT Hybrid Inverter Circuit Aging Production

The inverter main control board passes 72-hour full load aging test, MPPT tracking chip imported high-precision model, automatic identification of solar voltage to adjust charging power. The whole machine shell adopts IP20 dustproof design, internal heat dissipation fan automatic temperature control to reduce power attenuation under long-time operation.

LiFePO4 Battery BMS Protection Assembly

LiFePO4 cell grouping with capacity grading, built-in multi-layer BMS protection board to monitor single cell voltage in real time, prevent overcharge and over-discharge. The wall-mounted cabinet is made of thickened cold rolled steel with anti-rust spray coating, reserved communication wiring port for remote background monitoring.

Standardized Export Wooden Packing & Pre-Delivery Inspection

Each complete system adopts shockproof wooden pallet export packaging, all components wrapped with foam lining to avoid glass panel breakage, shell deformation and circuit damage during long-distance sea transportation. Every full set passes continuous solar charging and AC load full-power aging test before shipment, filtering out defective products with insufficient power generation, unstable inversion and battery failure.

Product Qualification of Off-Grid Solar Energy Storage System

Monocrystalline Solar Panel Conversion Efficiency & Power Tolerance Test Certificate: 610W module power output qualification report.
MPPT Hybrid Inverter Overload, Short Circuit Protection Safety Test Document: Pure sine wave AC output parameter verification.
LiFePO4 Battery Cycle Life & BMS Protection Performance Test Certificate: Long-term energy storage safety qualification.
IP65 Combiner Box Waterproof & Surge Protection SPD Test Record: Outdoor lightning protection performance certification.
Whole System Continuous Operation Aging Test Report: 24-hour full-load stable power generation qualification for engineering projects.

Deliver, Shipping and Serving of Off-Grid Solar Energy Storage System

01/

Packaging & Bulk Delivery

Full set integrated wooden pallet shockproof export packaging; mixed power bulk order matching is supported for photovoltaic engineering contractors and cross-border new energy wholesalers. We support EXW, FOB, CIF international trade terms, stable spot stock for 5/10/15/20/30/40KW six power models, fast customized production cycle for large engineering orders.

02/

Comprehensive After-Sales Support for Cross-Border Sellers

We provide full English photovoltaic system installation drawings, engineering scene renderings, system operation manuals and cross-border listing copy materials for all wholesale clients. Core components enjoy long-term official warranty; if customers receive damaged panels, defective inverters or faulty batteries caused by logistics collision within warranty period, we provide free replacement or proportional compensation according to actual damage conditions. Our professional new energy engineering customer service team replies to all inquiries about power model matching, load calculation, installation construction, bulk engineering pricing and photovoltaic export certification documents within 24 working hours, solving all system matching problems efficiently.

FAQ of Off-Grid Solar Energy Storage System

Q1: What is the difference between different power models?

A: The core difference lies in maximum AC output power, solar panel quantity and battery capacity. Small power 5/10KW is for household daily light load; high power 30/40KW supports large inductive loads such as water pumps and air conditioners for full-load continuous power supply.

Q2: Can this system work without solar light for several consecutive rainy days?

A: The matched LiFePO4 battery pack stores enough electricity to support several days of basic load power supply under continuous cloudy and rainy weather; sufficient sunlight during the day can fully replenish battery power.

Q3: Is professional electrician required for installation?

A: The product comes with complete English installation wiring diagram, but the system involves high DC voltage and 220V AC circuit, it is recommended to be installed by professional photovoltaic electricians to avoid safety hazards.

Q4: Can the system be expanded later to increase power?

A: Yes, the MPPT inverter supports parallel expansion, solar panels and battery packs can be added according to later load growth demand to upgrade system power capacity.
